ellipse

Shape #shape #ellipse

ellipse(x, y, w, h, [stroke=#000000], [fill=#FFFFFF], [weight=1.00])

Draw an ellipse

Syntaxe

ellipse(x=10, y=10, w=50, h=100, stroke="#000000", fill="#FFA000", weight=4)

Arguments

Name	Required	Default	Description
`x`	yes	-	x-coordinate of the center
`y`	yes	-	y-coordinate of the center
`w`	yes	-	width of the ellipse
`h`	yes	-	height of the ellipse
`stroke`	-	#000000	Stroke color
`fill`	-	#FFFFFF	Fill color
`weight`	-	1.00	Stroke weight (thickness)

Full example

var palette = palette_blend("#C74538", "#4DD0E1", 10);

var cycle = 3;

canvas(800, 800, "#37474F", center=true);

var padding = 20;
var x = 0;
var y = 0;
var radius = height()/2 - padding;

fill("transparent");
weight(2);

var col = 0;
var totalRings = length(palette) * cycle;

for (var j = cycle*2; j < totalRings-cycle; j++) {
    var currentRadius = radius - j * (radius / totalRings);
    stroke(palette[j % length(palette)]);
    ellipse(x, y, radius, currentRadius);
    ellipse(x, y, currentRadius, radius);
}

save("ellipse.png");
